DIN 7504Q Online Drawing Generator & Dimensions

Hexagon flange head drilling screws with collar

Use this DIN 7504Q online drawing generator to review the Hexagon flange head drilling screws with collar geometry and configure diameter, pitch, length, head and drive dimensions. Export a technical PDF drawing for sourcing, engineering review or custom manufacturing. Searches for DIN 7504Q, DIN7504Q, DIN 7504Q drawing and DIN 7504Q dimensions refer to this page.

Standards
  • DIN 7504Q
Back to Self-drilling screwsCompare DIN 7504Q equivalents and replacement →

Create Your DIN 7504Q Drawing Online

Use this DIN 7504Q drawing generator to configure dimensions, review the technical drawing and export a custom drawing for manufacturing. Whether the specification is written as DIN 7504Q or DIN7504Q, this online drawing tool covers the same Hexagon flange head drilling screws with collar standard reference.

Configure Your DIN 7504Q Hexagon flange head drilling screws with collar Drawing

Select the available size parameters, review the dimensional values and prepare a drawing-based specification. Material, grade, finish, tolerances, inspection and documentation requirements can be added to the manufacturing inquiry.

DIN 7504Q

Hexagon flange head drilling screws with collar

Technical Data Sheet

ETERNAL FASTENER
Wuxi, Jiangsu, China
Email: [email protected]
Web: www.fasteneref.com
WhatsApp: +8615951571207
DIN 7504Q
DIN 7504Q Hexagon flange head drilling screws with collar
Product code
Product specification
ST2.9x9.5
Product standard
DIN 7504Q
Material / grade
Steel 45
Unit
mm
Mechanical properties
45H
DIN 7504Q technical drawing
Dimension
Parameter (mm)
Dimension
Parameter (mm)
d
ST2.9
P
1.1
L
8.75~10.25
a
1.1
dk
5.2~5.5
f
0.9
k
1.7
No.
1
M
3.4
t
1.81~2.21
dp
2.3
Drilling plate thickness
0.7~1.9
z
6.25

max = maximum; min = minimum

Material
Material type
Steel
Grade
45
Thread
Tolerance
Standard
Mechanical properties
Property class
45H
Standard
Tolerance
Product grade
Standard
Surface defects
Surface Treatment
Inspection & packaging
Ref. wt / 1000 pcs (kg)
Document No.: EF-DIN-7504QRevision: v1Issue date: 2026-09-24Page: 1 / 2

Technical Data Sheet

Dimensions & size table

Unit: mm

DimensionPa/maxdk/maxdk/minfkNo.Mt/mint/maxdp/maxDrilling plate thickness/minDrilling plate thickness/maxz/max
ST2.91.11.15.55.20.91.713.41.812.212.30.71.96.25
ST3.51.31.36.86.441.22.124.61.892.392.80.72.256.65
ST4.21.41.37.57.141.32.324.72.042.543.10.72.47.2
ST4.81.61.48.17.741.42.524.92.242.743.61.7538.7
ST5.51.81.69.59.141.5325.42.73.24.11.754.48.3
ST6.31.81.810.810.371.73.4373.023.534.81.755.2511
Document No.: EF-DIN-7504QRevision: v1Issue date: 2026-09-24Page: 2 / 2
