Custom & Non-Standard DIN 914 / ISO 4027 Cone-Point Set Screws

Hex Socket Set (Cone)

Need custom DIN 914 set screws? Use the DIN 914 / ISO 4027 truncated-cone point geometry as a starting drawing, then define thread size and pitch, overall length, hex-socket width and depth, cone-point diameter, angle and length, material, hardness, finish, tolerances and inspection. The approved drawing controls the finished non-standard part.

Standards
  • DIN 914
Back to Set screwsCompare DIN 914 equivalents and replacement →

Create Your DIN 914 Drawing Online

Use this DIN 914 drawing generator to configure dimensions, review the technical drawing and export a custom drawing for manufacturing. Whether the specification is written as DIN 914 or DIN914, this online drawing tool covers the same Hex Socket Set (Cone) standard reference.

Customize DIN 914 Cone-Point Set Screws

DIN 914 / ISO 4027 is the reference template, not a limit on the customer specification. Change the thread, length, socket, cone-point diameter, angle or length, hardness, coating and tolerances as required. Design the cone point together with the mating dimple or hole; do not substitute a flat, cup or dog point without engineering approval.

DIN 914

Hex Socket Set (Cone)

Technical Data Sheet

ETERNAL FASTENER
Wuxi, Jiangsu, China
Email: [email protected]
Web: www.fasteneref.com
WhatsApp: +8615951571207
DIN 914
DIN 914 Hex Socket Set (Cone)
Product code
Product specification
M6x10
Product standard
DIN 914
Material / grade
Steel 45
Unit
mm
Mechanical properties
45H
DIN 914 technical drawing
Dimension
Parameter (mm)
Dimension
Parameter (mm)
d
M6
P
1
L
9.71~10.29
e
3.44
s
3.02~3.08
t1
3.5

max = maximum; min = minimum

Material
Material type
Steel
Grade
45
General technical requirements
DIN 267-1
Thread
Tolerance
45H:5g6g; other classes:6g
Standard
DIN 13-15 DIN 13-12
Mechanical properties
Property class
45H
Standard
DIN ISO 898-5
Tolerance
Product grade
A
Standard
ISO 4759-1
Surface Treatment
black (heat or chemical); electroplatingDIN 267-9
Surface roughness
DIN 267-2
Inspection & packaging
DIN 267-5
Surface defects
Ref. wt / 1000 pcs (kg)
Document No.: EF-DIN-914Revision: v1Issue date: 2026-09-24Page: 1 / 2

Technical Data Sheet

Dimensions & size table

Unit: mm

DimensionPe/mins/mins/maxt/min
M1.40.30.8030.7110.7240.6
M1.60.350.8030.7110.7240.7
M1.80.350.8030.7110.7240.8
M20.41.0030.8890.9020.8
M2.50.451.4271.271.2951.2
M30.51.731.521.5451.2
M40.72.32.022.0451.5
M50.82.872.522.562
M613.443.023.082
M81.254.584.024.0953
M101.55.725.025.0954
M121.756.866.026.0954.5
M1426.866.026.0955.6
M1629.158.0258.1156.4
M182.511.4310.02510.1157.2
M202.511.4310.02510.1158
M222.513.7212.03212.1429
M24313.7212.03212.14210
Document No.: EF-DIN-914Revision: v1Issue date: 2026-09-24Page: 2 / 2

Related catalog products

Catalog fasteners commonly specified with this drawing family. Confirm size, material and property class against your project drawing.

Request a Quote for Custom DIN 914 Set Screws

Send the completed drawing with thread, length, hex socket, cone-point dimensions, material, hardness, finish, quantity and inspection requirements for engineering review and quotation.
